EWC 0809A Wholesale One Way Needle Clutch Bearing
EWC 0809A Wholesale One Way Needle Clutch Bearing
Product Description
EWC
Feature
EWC is a one way needle clutch which applied flexibly of the technology of small bearings ,and
make the structure more compact as well as higher performance.
This kind of clutch, the outer lane has raised angles, it is easy to make a reservation to lock, used in the fishing tackle (able to bear the sea water and corrode ), some paper money planes.
Data Sheet
| Item | EWC |
| Material | Outer: ST14 stainless steel or GCr15
Inner: Strengthen nylon |
| Inner dia. | 8 mm |
| Outer dia. | 12 mm |
| Width | 9 mm |
| Torque capacity | 0.49 Nm |
| Weight | 2.4 g |
| Port | Shanghai;Ningbo |
| Delivery time | 10-20days |
| Package | singer box or as your requirements |
| Application | Fishing machines |
Different Sizes For Your Reference
| Shaft Diameter | Bearing Designation | Mass (g) | Boundary Dimensions | Torque Capacity | |||||||
| mm | EWC series | 1WC series | EWC | 1WC | Fw | D1 | D2 | B | A | (N.m) | (kgf.cm) |
| (with resin spring) | (with metal spring) | ||||||||||
| 4 | EWC0406A EWC0406C | - | 1 | - | 4 | 8 | 8.4 | 6 | 2.6 | 0.08 0.15 | 0.8 |
| - | - | 1.5 | |||||||||
| 6 | EWC0606XA EWC0606XC | - | 1.4 | - | 6 | 10 | 10 | 6 | 2.8 | 0.19 0.33 | 1.9 |
| - | - | 3.4 | |||||||||
| EWC0608A EWC0608C | - | 1.7 | - | 8 | 0.25 0.44 | 2.5 | |||||
| 1WC0608 | 2 | 4.5 | |||||||||
| - | 1WC0612 | - | 3 | 12 | 0.88 | 9 | |||||
| 8 | EWC0809A EWC0809C | - | 2.4 | - | 8 | 12 | 12 | 9 | 2.6 | 0.49 0.88 | 5 |
| - | - | 9 | |||||||||
| EWC0812A EWC0812C | - | 5.8 | - | 14 | 15 | 12 | 3.6 | 1.18 1.96 | 12 | ||
| 1WC0812 | 7 | 20 | |||||||||
| - | 1WC0815 | - | 8 | 15 | 2.65 | 27 | |||||
| 10 | EWC1010A | - | 5.2 | 10 | 16 | 17 | 7 | 1 | 10 | ||
| - | 1WC100914 | - | 3 | 14 | 14 | 9 | 2.5 | 2.25 | 23 | ||
| EWC1010A EWC1010C | - | 6 | - | 16 | 17 | 10 | 5 | 1.18 1.96 | 12 | ||
| - | - | 20 | |||||||||
| EWC1012A EWC1012C | - | 6.8 | - | 12 | 1.37 2.35 | 14 | |||||
| 1WC1012 | 8 | 24 | |||||||||
| 12 | EWC1209C | - | 6.2 | - | 12 | 18 | 19 | 9 | 5.1 | 3.04 6.28 | 31 |
| - | 1WC1216 | 12 | 16 | 64 | |||||||
