China Bearings HK08x14x12 for Lawn Mower Wheel Drawn Cup Needle Roller Bearing Manufacturer and Supplier

Bearings HK08x14x12 for Lawn Mower Wheel Drawn Cup Needle Roller Bearing

Short Description:

Send email to us Download as PDF

Product Detail

Product Tags

HK08x14x12 for Lawn Mower Wheel Drawn Cup Needle Roller Bearing

Product Description

Data Sheet

Item	HK
Material	ST14
Inner dia.	8 mm
Outer dia.	14 mm
Width	12 mm
Delivery time	7-10days
Package	Wooden box, tube, pulley, etc
Application	fishing machinery, ATM, Counting machine, Printer, copier, etc
OEM	Accept

Feature

HK is a one way needle clutch which applied flexibly of the technology of small bearings ,and

make the structure more compact as well as higher performance.

Different Sizes For Your Reference

Shaft Diameter	Bearing Designation		Mass Approx	Boundary Dimension			Basic Load Rating		Limiting Speed
Shaft Diameter	Curent Code	Original Code	Mass Approx	Fw	D	C	Dynamic	Static	Oil
mm	Curent Code	Original Code	g	mm			N		rpm
3	HK0306TN			3	6.5	6	1320	950	6000
3	BK0306TN			3	6.5	6	1320	950	6000
4	HK0408TN	37941/4	1.6	4	8	8	1540	1070	40000
4	BK0408TN	1476037	1.8	4	8	8	1540	1070	40000
5	HK0509TN			5	11	9	2200	1790	36000
	HK0509	47941/5	2	5	9	9	2200	1790	36000
	BK0509	45941/5	2.1	5	9	9	2200	1790	36000
	HK0510			5	9	10
6	HK0606			6	10	6
	HK0607	27941/6	1.8	6	10	7	1600	1400	30000
	HK0608	37941/6	2.1	6	10	8	1830	1550	32000
	BK0608	35941/6	2.2	6	10	8	1830	1550	32000
	HK0609	47941/6	2.2	6	10	9	2650	2400	30000
	BK0609	45941/6	2.6	6	10	9	2650	2400	30000
	HK0611		2.3	6	10	11	1700	1500	29000
	HK06X12X8	745613	2.5	6	12	8	2230	2010	33000
7	HK0708			7	11	8	2800	2150	27000
	HK0709	47941/9	2.3	7	11	9	2800	2150	27000
	BK0709	45941/9	2.9	7	11	9	2800	2150	27000
	HK0712			7	11	12
	HK07X12X08		2.2	7	12	8	3300	3220	37000
	HK07X12X09		2.4	7	12	9	3400	3150	37000
8	HK0808	37941/8	2.7	8	12	8	2550	2400	21000
	HK0808TN			8	12	8
	BK0808	35941/8	3	8	12	8	2550	2400	21000
	HK0810	57941/8	3	8	12	10	3700	3450	21000
	BK0810	88941/8	3.4	8	12	10	3700	3450	21000
	HK0812	67941/8		8	12	12
	HK08X14X10	27942/8	5.35	8	14	10	3800	3950	25000
	BK08X14X10	25942/8	5.8	8	14	10	3800	3950	25000
	HK08X14X12	37942/8	6.6	8	14	12	4100	4320	25000
9	HK0908	37941/9	3	9	13	8	3650	4050	25000
	BK0908	35941/9	3.4	9	13	8	3650	4050	25000
	HK0910	57941/9	4	9	13	10	4050	4250	25000
	BK0910	55941/9	4.3	9	13	10	4050	4250	25000
	HK0911		4.1	9	13	11	4300	4700	25000
	HK0912	67941/9	4.6	9	13	12	5000	6000	25000
	BK0912	65941/9	4.9	9	13	12	5000	6000	25000
	HK09X15X10	27942/9	5.6	9	15	10	5300	6300	25000
10	HK10X13X08		3.5	10	13	8	4100	4800	20000
	HK1010	57941/10	4.1	10	14	10	3900	4800	19000
	BK1010	55941/10	4.3	10	14	10	3900	4800	19000
	HK1012	67941/10	4.8	10	14	12	5000	6300	19000
	BK1012	65941/10	5	10	14	12	5000	6300	19000
	HK1015		6	10	14	15	6700	7800	19000
	BK1015		6.2	10	14	15	6700	7800	19000
	HK10X15X15	644900	6.5	10	15	15	6800	8800	18000
	HK10X16X10		6.5	10	16	10	6800	8800	18000
	BK10X16X10		6.8	10	16	10	6800	8800	18000
	HK10X16X12	DBl012	7.5	10	16	12	6800	8800	18000
	HK10X16X15	2207070	11	10	16	15	6800	8800	19000
	HK10X17X15		11.5	10	17	15	7200	8000	19000
	HK10X18X12		8.5	10	18	12	7200	8000	19000
12	HK1208	37941/12	3.3	12	16	8	7200	8000	19000
	HK1210	57941/12	4.6	12	16	10	4150	5800	19000
	BK1210	55941/12	5.2	12	16	10	4150	5800	19000
	HK1212	67941/12	5.6	12	18	12	3800	5100	15000
	BK1212	65941/12	6.2	12	16	12	3800	5100	15000
	HK12X17X12	2206766	7.5	12	17	12	5100	7000	15000
	HK12X17X15	2207131	9.5	12	17	15	5100	7000	15000
	HK12X17X18	2207496	11	12	17	18	5100	7000	15000
	HK12X18X12	37942/12	9.1	12	18	12	5500	6300	17000
	BK12X18X12	35942/12K	10.3	12	18	12	5500	6300	17000
	HK12X18X14	67942/12	10.6	12	18	14	6500	6300	15000
	HK12X19X12		10	12	19	12	6800	7400	15000
